29611 JIS Stainless steel rubber hose fittings

Short Description:


Product Detail

FAQ

Basic Info

    Model No.: 29611

    Pressure: High Pressure

    Work Temperature: High Temperature

    Thread Type: Internal Thread

    Installation: Sleeve Type

    Material: Carbon Steel

    Type: Other

    Head Code: Hexagon

    Tolerance: 0.01mm – 0.02 Mm

    Application: Hose Fittings

    Technics: Forged

    Surface: Zinc Plating

    Color: White Or Yellow

    Seal: JIS GAS FEMALE 60° CONE SEAT SEAL

    Threads: BSP

    Shape: Straight Nipple Fittings

    Product Name: Stainless Steel Rubber Hose Fittings

Additional Info

    Packaging: carton and wooden case

    Productivity: 500000 pcs per month

    Brand: Topa hydraulic fittings

    Transportation: Ocean,Land,Air,DHL/UPS/TNT

    Place of Origin: Hydraulic Fittings from China

    Supply Ability: 500000 pcs hydraulic fittings per month

    Certificate: Hydraulic Fittings ISO

    HS Code: 73071900

    Port: Tianjin,Ningbo,Shanghai

Product Description

Stainless steel rubber Hose Fittings

Rubber Hose fittings Material checking: strictly control of material using, meet international requested standards;
First inspection: Check first rubber hose fittings in each procedure.
Semi-finished rubber hose fittings inspection: in working process, workers check size as per drawing and check thread with thread gauge ;
Production line test: Quality Inspector will inspect machines, lines and rubber hose fittings at any time and any place.
Finished product inspection: inspection department will test and check before rubber hose fittings are plated zinc.
After plate zinc: also need to check rubber hose fittings size, crimp nut, quantity and finally check again, then packed and loaded

Hydraulic Fittings datas:

stainless steel hose fittings

29611 JIS HOSE FITTING, JIS GAS FEMALE 60° CONE SEAT SEAL .

E HOSE BORE DIMENSIONS
PART NO. THREAD E DN DASH C S1 S2
29611-02-03 G1/8″X28 5 03 6.5 14 14
29611-04-04 G1/4″X19 6 04 8 19 19
29611-06-06 G3/8″X19 10 06 9 22 22
29611-08-08 G1/2″X14 12 08 12 27 27
29611-10-10 G5/8″X14 16 10 11.5 20 30
29611-12-12 G3/4″X14 20 12 13.5 32 32
29611-16-16 G1″X11 25 16 16 41 41
29611-20-20 G1.1/4″X11 32 20 18.5 50 50
29611-24-24 G1.1/2″X11 40 24 19 55 55
29611-32-32 G2″X11 50 32 23 70 70

Package:

All stainless steel hose fittings orders are packaged in-house by our employees in strong cartons wrapped in protective caps. All packages of Bsp Hose Fittings are clearly labeled with text. Then we will put boxes into an wooden case with a big plastic bags.

Bsp Hose Fittings

Factory details:

TOPA company is specialized in manufacturing and selling fluid flow systerm. Our hydraulic products includes: All kinds of stainless hose fittings, adapters, Hydraulic Hose, High Pressure Hose assemblies and other metal parts, as well as the agent for related fluid joint products. We also provide stainless hose fittings OEM service.
These stainless hose fittings are mainly used in aerospace, automotive, shipbuilding, medicine, chemicals, petroleum and other areas.

stainless hose fittings

Application:

stainless hose fittings is widely used in the hydraulic and fluid conveying ststem of machinery,
oilfield, mine, building, transportation and other industries.

stainless hose fittings

FAQ:

1. How can you ensure the quality of your stainless hose fittings?
We will arrange stainless hose fittings sample confirmation before production. During the Hydraulic Fittings production, we have professional QC staffs control the quality and manufacture in accordance to the confirmed sample. We will also send you our material report and quality report with delivery.

2. Do you offer stainless hose fittings OEM service and can you produce as our drawings?
Yes. We offer stainless hose fittings OEM service. We accept custom design and we have a professional design team who can design stainless hose fittings based on your requirements. And we can develop new hydraulic Fittings products according to your samples or drawings

3. Can we design the packaging for stainless hose fittings?
Yes, you can indicate the dimensions of the carton and pallet.

4. Do you offer stainless hose fittings free samples?
We can provide Hydraulic Fittings free samples and you should pay the freight. After you place an order, we will give back the freight

5. What’s your delivery time for Hydraulic Fittings orders?
Generally, we will arrange shipment with 25 days after receiving the deposit. If urgent, we can also meet your requirement

Contact us:

stainless hose fittings

Looking for ideal Stainless Steel Hose Fittings Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Stainless Hose Fittings are quality guaranteed. We are China Origin Factory of Rubber Hose Fittings. If you have any question, please feel free to contact us.

Product Categories : Hydraulic Hose Fitting > British Hydraulic Fitting
