87391 Parker hydraulic swivel elbow fittings

Short Description:


Product Detail

FAQ

Basic Info

    Model No.: 87391

    Pressure: High Pressure, 3000psi

    Work Temperature: High Temperature

    Thread Type: Other

    Installation: Other

    Material: Carbon Steel

    Type: Other

    Head Code: Flange Round

    Tolerance: 0.01mm – 0.02 Mm

    Application: Hydraulic Elbow Fittings

    Technics: Forged

    Surface: Zinc Plating

    Color: White Or Yellow

    Seal: 87391 3000PSI Flange

    Shape: Straight Flange Fittings

    Product Name: Parker Hydraulic Swivel Elbow Fittings

Additional Info

    Packaging: carton and wooden case

    Productivity: 500000 pcs per month

    Brand: Topa hydraulic fittings

    Transportation: Ocean,Land,Air,DHL/UPS/TNT

    Place of Origin: Hydraulic Elbow Fittings from China

    Supply Ability: 500000 pcs Hydraulic Elbow Fittings per month

    Certificate: Hydraulic Elbow Fittings ISO

    HS Code: 73071900

    Port: Tianjin,Ningbo,Shanghai

Product Description

Parker hydraulic swivel elbow fittings

Hydraulic Elbow Fittings Material checking: strictly control of material using, meet international requested standards;
First inspection: Check first Hose Pipe Fittings in each procedure.
Semi-finished Hose Pipe Fittingsinspection: in working process, workers check size as per drawing and check thread with thread gauge ;
Production line test: Quality Inspector will inspect machines, lines and Hose Pipe Fittings at any time and any place.
Finished product inspection: inspection department will test and check before Hydraulic Elbow Fittings are plated zinc.
After plate zinc: also need to check Hose Pipe Fittings size, crimp nut,quantity and finally check again, then packed and loaded

Hydraulic Fittings datas:

Hydraulic Elbow Fittings

87391 3000PSI Flange, 90°SAE Flange 3000PSI

PART NO. FLANGE SIZE DN DASH F H B L
87391-08-08 1/2″ 12 08 30.2 47 23.9 7
87391-12-12 3/4″ 20 12 38.1 63 31.7 7
87391-16-16 1″ 25 16 44.4 68.5 38 8.2
87391-20-20 1.1/4″ 32 20 50.8 79.5 43.2 8.2
87391-24-24 1.1/2″ 38 24 60.3 98 50.3 8.2
87391-32-32 2″ 51 32 71.4 118.3 62.2 9.8
87391-40-32 2.1/2″ 51 32 84.1 140 74.4 9.8

Package:

All Hydraulic Swivel Elbow Fittings ;orders are packaged in-house by our employees in strong cartons wrapped in protective caps. All packages of Hydraulic Elbow Fittings ;are clearly labeled with text. Then we will put boxes into an wooden case with a big plastic bags.

Hydraulic Swivel Elbow Fittings

Factory details:

TOPA company is specialized in manufacturing and selling fluid flow systerm. Our hydraulic products includes: All kinds of Hydraulic Elbow Fittings, adapters, Hydraulic Hose, High Pressure Hose assemblies and other metal parts, as well as the agent for related fluid joint products. We also provide Hydraulic Elbow Fittings OEM service.
These Hydraulic Elbow Fittings are mainly used in aerospace, automotive, shipbuilding, medicine, chemicals, petroleum and other areas.

Hydraulic Swivel Elbow Fittings

Application:

Hydraulic Elbow Fittings is widely used in the hydraulic and fluid conveying ststem of machinery,
oilfield, mine, building, transportation and other industries.

Hydraulic Swivel Elbow Fittings

FAQ:

1. How can you ensure the quality of your Hydraulic Elbow Fittings?
We will arrange Hydraulic Elbow Fittings sample confirmation before production. During the Hydraulic Fittings production, we have professional QC staffs control the quality and manufacture in accordance to the confirmed sample. We will also send you our material report and quality report with delivery.

2. Do you offer Hydraulic Elbow Fittings OEM service and can you produce as our drawings?
Yes. We offer Hydraulic Elbow Fittings OEM service. We accept custom design and we have a professional design team who can design Hydraulic Elbow Fittings based on your requirements. And we can develop new hydraulic Fittings products according to your samples or drawings

3. Can we design the packaging for Hydraulic Elbow Fittings?
Yes, you can indicate the dimensions of the carton and pallet.

4. Do you offer Hydraulic Elbow Fittings free samples?
We can provide Hydraulic Fittings free samples and you should pay the freight. After you place an order, we will give back the freight

5. What’s your delivery time for Hydraulic Fittings orders?
Generally, we will arrange shipment with 25 days after receiving the deposit. If urgent, we can also meet your requirement

Contact us:

Hydraulic Elbow Fittings

Looking for ideal Hydraulic Elbow Fittings Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Hydraulic Swivel Elbow Fittings are quality guaranteed. We are China Origin Factory of Parker Elbow Fittings. If you have any question, please feel free to contact us.

Product Categories : Hydraulic Hose Fitting > American Hydraulic Fitting
