Split Hydraulic Fittings Stainless Steel Light 3000psi Sae Flange Clamp

Short Description:

2 Inch Mounting High Quality Split Hydraulic Fittings Solid Stainless Steel Light 3000psi Sae Flange Clamp

Black metal split flange is commonly used world wide to connect larger sizes of hose and tubing (3/4” to 3”) in fluid power systems.
Carbon steel split flange come in two pressure classes. The standard series, Code 61, which goes to 3,000 psi and the high pressure series, Code 62, where all the sizes are rated at 6,000 psi.

Product Detail


Split Hydraulic Fittings Stainless Steel Light 3000psi Sae Flange Clamp

Hydraulic flange clamp is belong to hydraulic flange system, it used to connect hydraulic flanged tube, hydraulic hose assemblies and piping. You can find this flange connection to hydraulic cylinder in excavator and loader.

black metal split flange

Sae flange clamp Description
Flange Clamps – Clamps are used for providing the holdingpower to the 4-bolt flange connection. They are offered in split and captive (one-piece) versions. Flange clamps are forged for higher strength and durability.

split flange

Pipe flange clamp Applications

Pressed flange clamp widely applied in various hydraulic systems in the following fields of industry: Industrial Hydraulics, Injection Moulding Machinery, Aluminium Die-Casting Machinery, Sintering Machinery, Steel Mills, Hydraulic Presses, Paper Processing, Mobile Hydraulics, Building Machinery, Agricultural Machinery, Forestry Machinery, Lifting and Material Handling Equipment…

flange clip

Flange clamps Advantage
Flange pipe clamp are used as a reliable alternative to regular pipe and tube connectors. Their biggest advantage is the considerably higher pressure resistance for many sizes and the continuous pressure level of the High Pressure Series which can operate with maximum working pressures of up to 400 bar.

sae j518 split flange clamps 3000psi

About US

Topa is the professional hydraulic fitting and hose solution provider. We not only sell hydraulic fitting and hose, but also provide solutions to customers.

Our main products are hydraulic flange clamp, hydraulic fittings, hydraulic hose, adapters and related products.

In TOPA you will find exactly products you want. We are a one-stop manufacturer for all your hydraulic products needs!

carbon steel split flange

Stainless steel flange clamps Package
1. sae j518c flanges use plastic film bag inside;
2. mounting flange clamp’ cartons with model, quantity, size mark;
3. sae split flange clamp’s use pallet packaging;
4. split flange exhaust clamp accepts customized pallet sizes;

split flange clamp



sae j518c flanges

Flange clip Related Products

sae whole flange clamps 6000psi

How to contact us?

For more information about the sae j518 hydraulic thread flange, please contact us.

sae whole flange clamps 3000psi
